MD-S275 Smart Wireless Digital Pressure Gauge 4G/NB/LoRa/LoRawan

Short Description:

Supports a variety of wireless communication methods, including 4G, NB-IoT, LoRa, and LoRaWAN.
Features an overall IP67 protection rating, enabling long-term deployment in outdoor environments.
Facilitates remote debugging via “Da Lan Mao” and on-site debugging via Bluetooth, simplifying device operation and maintenance.
Housed in a die-cast aluminum casing, offering superior durability and resistance to drops and vibration for enhanced product protection.
Equipped with a detachable antenna; in scenarios with weak signal strength, the standard antenna can be replaced with an extended version.
Supports multi-protocol adaptation, allowing seamless integration with various custom protocols.
Includes anomaly detection and alarming capabilities, supporting alerts for internal device faults.

Send email to us

Product Detail

Product Tags

Features:

The MD-S275 is an intelligent, wireless, and outdoor-grade digital pressure gauge powered by a lithium battery. Featuring an IP67 protection rating, it is designed for long-term deployment on outdoor pressure pipelines. Its lithium battery power source, combined with a low-power design, ensures a normal operating lifespan of 2 to 3 years. Furthermore, the device supports a range of mainstream wireless communication protocols, including 4G, NB-IoT, LoRa, and LoRaWAN. Parameters can be configured-and firmware updated-either locally via a dedicated Bluetooth app or remotely via the "DaLanMao" platform, thereby simplifying the work for installation and maintenance personnel. Finally, the device employs a dual-mode data transmission strategy-sending routine data at scheduled intervals while immediately transmitting alarm data-to ensure the utmost timeliness in alerting.

Application:

Fire Water System
Domestic Water Piping Network
Water Supply Network

Technical Parameters:

Measurement Range	0–2.5 MPa (Other ranges available)
Accuracy	0.5%FS
Power Supply	3.6 V Lithium Battery
Mounting Method	M20×1.5, G1/2, G1/4 (Other threads available upon request)
Protection Class	IP67
Overload Pressure	≤10 MPa: 200% FS; >10 MPa: 150% FS
Operating Temperature	-20 ～65°C
Output Type	4G, NB-IoT, LoRa, LoRaWAN
Operating Duration	≥3 years (10-second sampling, 2-hour upload interval)
Sampling Rate	1 ～600 s
Display	Full-screen LCD
Product Material	Cast Aluminum Housing
Ambient Temperature:	-20 to 65°C
Relative Humidity:	0–100% RH (Non-condensing)
Storage Temperature:	-10 to 50°C
