MDS542Z Digital Remote Pressure Gauge RS485 | IP67 LCD Red/Green Alarm | For Gas Fire Suppression Systems

Short Description:

High Protection Rating (IP67)
Red and Green Alarm Indicators for Enhanced Visual Clarity
High Product Stability with Built-in Electromagnetic Interference Protection
Wide Operating Temperature Range, Suitable for Most Media
LCD Screen Display
Compliant with the New National Standard GB25972-2024 for Gas Fire Extinguishing Systems and Components
Integrated Welded Construction; Oil-Free Design Ensures Zero Leakage for the Entire Service Life

Send email to us

Product Detail

Product Tags

Features:

The digital remote-transmission pressure gauge is designed for real-time pressure monitoring and alarm indication. This product features an LCD screen for display and utilizes red and green indicators for alarms. Different indicator colors are employed to distinguish between normal pressure, under-pressure, and over-pressure conditions, allowing users to intuitively observe the pressure alarm status. It incorporates an integrated, oil-free welding process, a professional sensor conditioning circuit, and the standard MODBUS-RTU protocol. Key features include a compact size, stable performance, and corrosion resistance. It is primarily used for pressure monitoring in fire-extinguishing gas cylinders and tanks.

Application:

Fire Suppression Gas Cylinder Monitoring

Technical Parameters:

Range	0-6/10/16/24/30Mpa
Accuracy	0.5%FS
Out	RS485
Mounting Method	M10×1
Power	12-28VDC
Electrical Protection:	Power Frequency Interference Suppression Design
Display	LCD
IP Rating	IP67
USE Humidity:	(0~95%)RH
USE Temperature:	(-20~80)℃
