MD-S963KZ Waterproof ABS/Polycarbonate Junction Box with Transparent Window & Hinged Cover
FEATURE
The MD-S963KZ Residual Pressure Controller is a terminal that is an important part of the residual pressure monitoring system. It communicates with the residual pressure controller using a non-polarized two-wire bus, receives signals from residual pressure sensors, and processes them centrally to control the action of the pressure relief valve actuator, thereby controlling the opening and closing of the bypass pressure relief valve to ensure the residual pressure value remains within the normal range specified by requirements.
It has a compact appearance and can be installed inside the power distribution control box of the positive pressure supply fan in the monitored area, or it can be housed in an additional box and placed outside next to the power distribution box according to actual conditions.
APPLICATION
☑Positive pressure air supply system
TECHNICAL PARAMETERS
| Working Power Supply | AC220V, 50Hz |
| Load Capacity | 64 units |
| Display Method | LCD screen display |
| Communication Method | Two-wire bus |
| Communication Distance | ≤1500 meters |
| Alarm Method | Sound and light alarm |
| Housing Material | Plastic |
| Product Dimensions | (130.36*96.00*55.60)mm |
| Operating Temperature | (-20~65)℃ |
| Operating Humidity | ≤95% (non-condensing) |
| Installation Method | DIN rail mount |
| Control Output | 24VDC controls damper actuator |
DIMENSION
GUIDE SELECTION
| MD-S963KZ | P4 | D5 |
| Model S963KZ Residual Pressure Controller |
Power Supply Method P4 (220V AC) |
Installation Method D5 (DIN rail mount) |
Notes:
1. There may be product selections that do not correspond directly. Please visit the company website www.meokon.com for inquiries or consult with technical engineers.
2. The specifications provided in this document represent the technical status at the time of publication. We reserve the right to change specifications and materials without prior notice.
