MD-S909P Industrial IoT Remote Terminal Unit (RTU) with 4G & Ethernet – 16-Channel DI & 8-Channel AI Data Acquisition Module

Short Description:

☑ Dual-network communication design: Wireless 4G and Ethernet
☑Input/output configuration:
8 analog input channels
8/16 digital input (DI) channels
4 relay output channels
☑Communication interfaces:
2 RS485 bus interfaces
1 RS232 bus interface
☑Power failure alarm function

Send email to us

Product Detail

Product Tags

FEATURE

This product is a multifunctional data acquisition and remote transmission terminal. It is equipped with a 16-channel DI (digital input) switch quantity input module, which can realize real-time monitoring of the power status, operation status, fault status, and manual/automatic status of fire pump control cabinets, fan control cabinets, and other equipment. The 8-channel 4-20mA input enables real-time monitoring of pressure, liquid level, and valve opening.

APPLICATION

· Smart building
· Smart industrial park
· Smart fire protection system
· Smart water management
· Smart pump station

TECHNICAL PARAMETERS

Communication method	4G full network
Signal input	8 analog inputs, optional 4/8/16 switch inputs
Ethernet interface	10/100M adaptive
Signal output	without relay output/4-channel relay output
Bus interface	RS4852, RS2321
Installation method	Wall - mounted
data configuration	Local USB interface, remote configuration, Bluetooth configuration
Size	(297×210×78)mm
Power supply	AC220V
Shell material	Iron plate
Operating temperature	(-20~+80) ℃
Storage temperature	Temperature (-10~50 ℃) humidity (0~95% RH)
Antenna	Suction cup antenna
