MD-S271V Wireless Vibration Monitoring Sensor with 4G/LoRa/NB-IoT | IP68 Industrial IoT Condition Monitoring Sensor

Short Description:

Range:0~20mm/s Accuracy:5%FS Power supply:DC3.6V
4G/LoRa/LoRaWAN/NB-iot wireless transmission method
Remote parameter setting,remote software upgrade function (only supported by 4G)
Ultra-low power consumption design,lithium battery power supply
IP68 waterproof design,can be used in wet and underground working conditions for a long time

Send email to us

Product Detail

Product Tags

FEATURE

Multiple unit switching,high and low alarm values can be set,and messages can be sent immediately
Wireless transmission function
On/off function
Remote configuration or button setting of IP address,alarm point,upload frequency,etc.(4G/NB)
Equipped with a gateway to achieve efficient pressure monitoring within the local area network (LoRa)

The wireless sensor is a wireless instrument with a separate design between the sensor probe and the intelligent terminal.
This series of products is powered by batteries,which are easy to replace.The battery capacity and quantity can also be expanded according to the needs of working conditions.A variety of wireless transmission methods such as 4G/LoRa/LoRaWAN/NB-iot are
available.

This series of products has a waterproof rating of IP68 and is equipped with a mounting bracket.The designed load-bearing strength is better than 200Kg.It can be installed on walls,buried underground,and installed in complex working conditions such as fire wells and rainwater wells.
This series of products adopts magnetic installation.

APPLICATION

Fire pump room
Device monitoring

TECHNICAL PARAMETERS

Transfer Method	4G	LoRa	NB-IoT
Power Consumption	Highest	Lower	Higher
Transmission Distance	Depends on existing operator base station	Better than 3 km	Depends on NB base station
Gateway Configuration	None	LoRa Gateway	None
Internet Time	20 seconds	5 seconds	5 seconds
Tariff	Refer to local operator tariff standards	None	Refer to local operator tariff standards
Product Features	IP address and port can be set High and low alarm points can be set The sensor collection frequency can be set Upload frequency can be set Work status query	High and low alarm points can be set The sensor collection frequency can be set Upload frequency can be set Work status query	High and low alarm points can be set The sensor collection frequency can be set Upload frequency can be set Work status query
Message Format	Customizable message format	Transparent transmission protocol	Custom message format
