Featured Products
-
MD-S210 High precision digital pressure gauge ...
Technical Parameters:
105mm diameter,304 SS shell
5digits display, main & sub- screen dual screen design
10 units are available: MPa/kPa/psi/BAR/Pa/mBAR/mmHg/mH2O/Torr/Kgf/cm
low power design,3 AA batteries and can lasts up to 3600 hours
Product certificate: CE, Explosion Certificate Exib IICT4 -
-
China Meokon Pressure Transmitter Transducer Se...
Technical Characteristics:
Low power consumption design, 3.3V or 5V power supply
0.5-2.5V or RS485 output optional
316L stainless steel diaphragm, good impact resistance
Laser welding process to prevent leakage, IP68 waterproof design -
Pressure Transmitter China MEOKON
0.5-4.5V, 4-20mA outputSmall sizeGood stabilityHigh overloadTemperature range: -40…85ºC -
Explosion Case Type Industrial Pressure Sensor ...
Adopt 2088 Industrial explosion-proof shell
Anti-interference design, multiple setting functions
Intrinsically safe explosion-proof certificate and CE certificate
Support baud rate, address, filter constant setting (RS485 type)
Support display digits, filter coefficient, sensitivity coefficient, zero clear & other function (4~20mA type) -
Explosion-Proof Housing Industrial Pressure Sen...
Adopt 2088 Industrial explosion-proof shell
Anti-interference design, multiple setting functions
Intrinsically safe explosion-proof certificate and CE certificate
Support baud rate, address, filter constant setting (RS485 type)
Support display digits, filter coefficient, sensitivity coefficient, zero clear & other function (4~20mA type) -
Temperature Humidity Sensor Factories for Pump ...
68x50mm large screen LCD display
Anti-interference design, isolated output
4~20mA or RS485 output Optional
Support independent selection of range and key parameter configuration
Support 9~28V wide power supply -
Humidity and Temperature Sensor 4-20mA for Clea...
68x50mm large screen LCD display
Anti-interference design, isolated output
4~20mA or RS485 output Optional
Support independent selection of range and key parameter configuration
Support 9~28V wide power supply -
High Quality 0-10bar Capacitive Ceramic Press...
Product name: ceramic pressure sensor
pressure range: 0-20bar
dimension: diameter φ18, height is upon pressure range
excitation: 2.5…30Vdc,max
bridge impedance: 11KΩ±30%
full scale output: 3mV/V,type
operation temperature: -40~135℃
-
High Quality 0-10Bar Pressure Sensorwith 0.5-5V...
Product name: ceramic pressure sensor
pressure range: 0-20bar
dimension: diameter φ18, height is upon pressure range
excitation: 2.5…30Vdc,max
bridge impedance: 11KΩ±30%
full scale output: 3mV/V,type
operation temperature: -40~135℃
-
Imported Sensor Built-in Differential Pressure ...
Product DescriptionImported micro differential pressure sensor with high accuracy and good stabilityMultiple pressure units switching
High / low pressure alarm, sound / light alarm can be set
Multiple function: switch on / off, clear, peak record, sound and light alarm
Powered by 2 AA batteries, which lasts more than 12 months
The MD-S220 series differential pressure gauge adopts the original imported differential pressure sensor as the pressure-sensing element, combined with the ultra-low power digital conditioning circuit, which has the characteristics of high accuracy and long-term stability. The installation method is the same as the mechanical differential pressure gauge, which is convenient for engineers to install and debug on site.
This series of differential pressure gauges can be used for measurement and control of high-precision differential pressure in clean rooms, operation rooms, clean rooms, ventilation systems, and fan testing.
Product Parameters:Range -30~30/-60~60/-125~125/-250~250/-500~500Pa -1~1/-2.5~2.5/-5~5kPa Acc. 2 %FS (≤100Pa) 1%FS(>100Pa) Supply 3 AA batteries Overload Capacity 7kPa(<2kPa range) 5 x range(≥2kPa range) Refresh Rate 1S Long-term Stabilily Typical:±0.5%FS/year Zero Temperature Drift Typical:±0.02%FS/ºC,maximum±0.05 FS/ºC Power Supply 3V (2 AA batteries) 24VDC (optional) Working Current <0.2mA (non-alarm state) Operating Temperature -20~80ºC Compensation Temperature 0~40ºC Electric Protection Anti-reverse protection Measurement Medium Clean air Connection 3x5mm(ID:3mm OD:5mm)air nozzle Shell Material PA 66 IP Rating IP54 Product certificate CE With the accelerated application of cutting-edge technologies such as the Internet of Things, big data, artificial intelligence, and 5G, the development of smart ecology has gradually become the mainstream. Whether it is a smart city, smart security, or smart factory, smart security, the demand for smart meters is constantly growing. For this reason, various instruments and meters equipped with advanced sensors have become more widely used.
In some special application scenarios, because of the very strict requirements on the indoor environment or work environment, real-time and accurate monitoring of the differential pressure is required. In response to this market situation, Meokon integrated corporate R&D capabilities to design and manufacture MD-S220 series digital differential pressure gauges, and plans to officially launch them on the market in the near future to meet the actual needs of customers. So, what are the commendable advantages of this blockbuster new product?
First of all, the MD-S220 series digital differential pressure gauge that Meokon will launch “two-pronged”, not only uses the original imported differential pressure sensor as the pressure sensing element, but also is equipped with an ultra-low power digital conditioning circuit. The accuracy and stability are greatly improved, and the accuracy is better than 1% FS, and the relative advantage is obvious.
Secondly, considering the complexity of the actual application environment, the MD-S220 series digital differential pressure gauge adopts the same installation method as the mechanical differential pressure gauge, which enables engineers to obtain greater convenience when installing and debugging on site, and improves The efficiency of installation and debugging, and avoiding some unnecessary errors or hidden dangers, can be described as very considerate.
Product Application:FanFarmingCleanroomClean air conditioner -
China Digital Data Logger Pressure Gauge with F...
80mm diameter, 304 stainless steel case
Timing acquisition, USB output, support data export
With data software, special data communication line
It can store up to 10,000 pcs data, It displays range when switch on
With pressure display bar, indicating the current pressure percentage, One-button zero-clearing function
